Faster Cooling, Faster Comfort
Save on Energy Bills and the Planet

Good Work Goes Unnoticed

Efficient, Faster, Durable, Quieter

Traps Big Dust from the Start

Reduce Allergens for Healthier Air
An Internal Clean that’s Automatic
-
Easy-to-Monitor Energy Consumption
The display keeps you informed so you can easily monitor and reduce energy consumption*. *Energy consumption during A/C operation.
-
Environment-Friendly Refrigerant
Prevent environmental pollution with R32 refrigerant’s improved energy efficiency.
-
Control 4 Levels of Energy Consumption
Control energy consumption with 4 levels based on your needs, whether alone or with family.
-
Quick and Easy Installation
Enjoy cool air sooner with air conditioning that takes less time and effort to install.
-
A More Comfortable Sleeping Environment
Experience the most comfortable sleeping environment with automatically adjusting functions*. *When the comfort sleep function is activated.
-
Safety Against Voltage Fluctuation
Enjoy a durable air conditioner with an ability to withstand voltage fluctuation*. *LG Internally tested “rated voltage ± 30%” fluctuation and it may vary depending by environment.
DIMENSIONS

SUMMARY
-
- CAPACITY – MIN.~RATED~MAX.(BTU/H)
- 1,800 – 9,200 – 11,900
-
- DIMENSION INDOOR – (W × H × D MM)
- 837 x 308 x 189
-
- KEY FEATURE
- DUAL INVERTER COMPRESSOR
-
- KEY FEATURE
- 10 YEARS COMPRESSOR WARRANTY
COOLING CAPACITY
-
- Rated (Min – Max) Btu/h
- 9200(1,800 – 11,900)
POWER INPUT
-
- Rated (Min – Max) W
- 770 (150 – 1,000)
RUNNING CURRENT
-
- Cooling(A)
- 4.40
POWER SUPPLY
-
- Ø / V / Hz
- 1/220~240/50
MOISTURE REMOVAL
-
- l/h.
- 1.25
AIR FLOW RATE
-
- Indoor,Max (㎥/min)
- 10.5
- Outdoor,Max (㎥/min)
- 28.0
SOUND LEVEL
-
- Indoor,H/M/L/SL (dB(A))
- 39/33/27/21
- Outdoor,Max (dB(A))
- 50
DIMENSION
-
- Indoor Unit (WxHxD) (mm)
- 837 × 308 × 189
- Outdoor Unit (WxHxD) (mm)
- 720 × 500 × 230
NET WEIGHT
-
- Indoor Unit(kg)
- 8.7
- Outdoor Unit (kg)
- 21.7
PIPING CONNECTIONS
-
- Liquid (mm)
- Ø 6.35
- Gas (mm)
- Ø 9.52
PIPE EXTENSION
-
- Chargeless Pipe Length (m)
- 12.5
- Additional Refrigerant Gas (g/m)
- 15
-
- Maximum Pipe Length (m)
- 20
- Maximum Elevation Length (m)
- 15
AIR FLOW
-
- Air Supply Outlet
- 1
- Airflow Direction Control (Left & Right)
- Manual
-
- Airflow Direction Control (Up & Down)
- 6 Steps
- Auto Swing (Up & Down)
- Yes
-
- Fan Speed Steps (Fan / Cool / Heat)
- 6 / 6 / No
- Natural Wind (Auto Wind)
- Yes
-
- Jet Cool / Jet Heat (Power Wind)
- Yes / No
- Comfort Air
- Yes
AIR PURIFYING
-
- Prefilter (Washable / Anti-Bacteria)
- Yes
- Micro Dust Filter
- Yes
RELIABILITY
-
- Self Diagnosis
- Yes
- Dry (Dehumidification) Operation
- Yes
CONVENIENCE
-
- Auto Operation (Artificial Intelligence)
- Yes
- Auto Cleaning (Coil Dry)
- Yes
-
- Auto Restart Operation
- Yes
- Forced Operation
- Yes
-
- Sleep Mode
- 7hr
- Timer 24hr (On/Off) / 7hr (Off)
- Yes / No
-
- Smart Diagnosis
- Yes
- Indoor Unit Display Type
- Number Display
-
- Indoor Unit Display Light
- On/Off
ENERGY SAVING
-
- Energy Control
- Active Energy Control
INDIVIDUAL CONTROL
-
- Handheld Wireless Controller-Setting Temperature Range (Cooling)
- 16~30 °C (60~86 °F)
