- Standard Non-Inverter
- R32 Refrigerant
- BIG FLAP
- Up to 18% Faster Cooling
- 3 Starts Energy Rating
OVERVIEW
SPECIFICATIONS
Model
- Indoor (50Hz) : CS-PN9WKH-1
- Outdoor (50Hz) : CU-PN9WKH-1
- Refrigerant Type : R32
Cooling Capacity
- (min-max) kW : 2.78
- (min-max)Btu/h : 9,500
EER
- (min-max) Btu/hW : 11.59
- (min-max) W/W : 3.39
- CSPF : 3.48
Electrical Data
- Voltage (V) : 230
- Running Current (A) : 3.7
- Power Input (W) : 820
Moisture Removal
- L/h : 1.6
- Pt/h : 3.4
Air Circulation
- Indoor m³/min (ft³/min) : 10.9 (385)
- Outdoor m³/min (ft³/min) : 28.8 (1,020)
Noise Level
- Indoor (H/L/Q-Lo) (dB-A) : 38/26
- Outdoor (H / L) (dB-A) : 48
Dimensions
- Height (mm) : 290 (511)
- Height (inch) : 11-7/16 (20-1/8)
- Width (mm) : 779 (650)
- Width (inch) : 30-11/16 (25-19/32)
- Depth (mm) : 209 (230)
- Depth (inch) : 8-1/4 (9-1/16)
Net Weight
- Indoor kg (lb) : 8 (18)
- Outdoor kg (lb) : 21 (46)
Refrigerant Pipe Diameter
- Liquid Side (mm) : ø 6.35
- Liquid Side (inch) : ¼
- Gas Side (mm) : ø 9.52
- Gas Side (inch) : 3/8
Pipe Extension
- Chargeless Pipe Length (m) : 7.5
- Maximum Pipe Length (m) : 20
- Maximum Elevation Length (m) : 15
- Additional Refrigerant Gas* (g/m) : 10
- Power Supply : Indoor
Cleaner Air
- nanoe™X : No
- nanoe-G : No
- Anti-Dust Coating : No
- Dust Sensor : No
- Odour-Removing Function : Yes
- Removable, Washable Panel : Yes
Comfort
- Radiant Cooling : No
- iAUTO-X : No
- iAUTO : No
- ECONAVI : No
- ECO Mode with A.I. : No
- Temperature Wave : No
- SLEEP : Yes
- Inverter Control : No
- Powerful Mode : Yes
- Quiet Mode : Yes
- Soft Dry Operation Mode : Yes
- Personal Airflow Creation : No
- Airflow Direction Control (Up Down) : Yes
- Manual Horizontal Airflow Direction Control : Yes
Convenience
- 24-Hour Dual ON OFF Real Setting Timer : No
- 24-Hour ON OFF Real Setting Timer : Yes
- LCD Wireless Remote Control : Yes
- Wireless LAN Remote Control For Internet Connection : No
- Wired Remote Control : Yes (Optional)
Reliability
- Random Auto Restart (32 Restart Patterns) : Yes
- Blue Fin Condenser : Yes
- Long Piping (Numbers indicate the maximum pipe length) : 20m
- Top-Panel Maintenance Access : Yes
- Self-Diagnostic Function : No
NOTE
Please do not use copper pipes that are less than 0.6mm in thickness.
*When pipes are not extended from the standard pipe length, the required amount of refrigerant is already in the unit.
